The industries-first hydrogeneration capability
Spirit 1.0 Evo Electric Outboard Motor
Introducing Spirit 1.0 Evo
Spirit 1.0 Evo is a portable 3HP electric outboard made for dinghies, fishing boats, and sailboats. It features a 1276Wh large integrated lithium battery for long range. The hydrogeneration function is great for a sustainable sailing experience.
Hydrogeneration
Spirit 1.0 Evo is the first-ever electric outboard that features hydrogeneration. ePropulsion prides itself on being pioneers in the electric motors industry
The hydrogeneration data is based on real tests with the anti-ventilationThe hydrogeneration data is based on real tests with the anti-ventilation plate installed. plate installed.
Performance
At the core of Spirit 1.0 Evo electric outboard motor, it’s a 1kW BLDC motor, equivalent to 3HP.
| Power (W) | Speed (mph / kph) | Runtime (hh:mm) | Range (mile / km) | 35 | 2.2 / 3.5 | 36:25 | 80 / 129 |
|---|---|---|---|
| 65 | 2.7 / 4.3 | 19:35 | 53 / 85.3 |
| 125 | 3.5 / 5.6 | 10:00 | 35 / 56 |
| 250 | 4.4 / 7.1 | 5:00 | 22 / 35.5 |
| 500 | 5.3 / 8.5 | 2:30 | 13.3 / 21.3 |
| 750 | 5.7 / 9.2 | 1:40 | 9.5 / 15.3 |
| 1000 | 6.2 / 10 | 1:15 | 7.8 / 12.5 |
* The performance data is based on a 12-foot aluminum boat with one person and one Spirit battery Plus in calm lake water. The actual speed, range and running time may vary because of different boats, load, weather, etc.
With one charge, you can go 22 miles at 4.5 mph, or fish all day long at trolling speed.
Battery
Positive Buoyancy
Never worry if the battery drops into the water.
1276Wh Capacity
180W Solar Charging
E-Series Battery
Designed for Portability
Spirit 1.0 Evo outboard with battery is portable & easy to transport.
Lightweight
Carry Bag Set
Folding Tiller
Digital Operation
ePropulsion electric outboard motors are easy to operate and keep you informed of operation status.
- Digital DisplayYou have access to real-time power, remaining runtime, battery level, operating voltage, etc.
- Electric StartPress one button and you're ready to go. No more pulling the cord to start.
- Magnetic Kill SwitchStop's the motor in an emergency.
- Stepless throttle changingThe throttle hand feel is clear, smooth and enjoyable.
- Max Power Output AdjustmentWith a adjustable full throttle power, its safer for kids and rental boats
- Ambidextrous OperationtTurning throttle easily either from the left-hand or right-hand side.
-
Safety Wristband
- Easy-to-use.
- Man overboard protection
- Wireless connection
- Waterproof IP67
- Max connection up to 8 wristbands per motor
Remote Control Capability
The Spirit 1.0 Evo is the only electric outboard under 5HP on the market that allows remote helm steering. You can choose either the Evo top mount control or the Evo side mount control.
Spirit 1.0 Plus
The Entry-level Spirit Model
The Spirit 1.0 Plus has the same performance and the same runtime as the Spirit 1.0 Evo. As the entry-level Spirit model, it doesn’t feature hydrogeneration and the safety wristband.
Specs
| Spirit 1.0 Evo | Spirit 1.0 Evo Remote |
Power
|
Spirit 1.0 Evo
1 kW (3HP equivalent)
|
Spirit 1.0 Evo Remote
1 kW (3HP equivalent)
|
|---|---|---|
|
Standard Battery
|
Spirit 1.0 Evo
Spirit Battery Plus, 1276 Wh li-ion polymer
|
Spirit 1.0 Evo Remote
Spirit Battery Plus, 1276 Wh li-ion polymer
|
|
Input Voltage
|
Spirit 1.0 Evo
39V – 60V
|
Spirit 1.0 Evo Remote
39V – 60V
|
|
Motor Weight*
|
Spirit 1.0 Evo
11.3 kg / 24.9 lbs
|
Spirit 1.0 Evo Remote
10.6 kg / 23.4 lbs
|
|
Battery Weight
|
Spirit 1.0 Evo
8.7 kg / 19.2 lbs
|
Spirit 1.0 Evo Remote
8.7 kg / 19.2 lbs
|
|
Charging Time
|
Spirit 1.0 Evo
Standard charger: 8.5 Hrs Fast charger: 3.5 Hrs
|
Spirit 1.0 Evo Remote
Standard charger: 8.5 Hrs Fast charger: 3.5 Hrs
|
|
External Battery
|
Spirit 1.0 Evo
Yes, and E-Series Battery recommended
|
Spirit 1.0 Evo Remote
Yes, and E-Series Battery recommended
|
|
Propeller
|
Spirit 1.0 Evo
11″ × 5.8″ 2-blade composite propeller
|
Spirit 1.0 Evo Remote
11″ × 5.8″ 2-blade composite propeller
|
|
Trim / Tilt Angle
|
Spirit 1.0 Evo
0°, 7°, 14°, 21° / 85°
|
Spirit 1.0 Evo Remote
0°, 7°, 14°, 21° / 85°
|
|
Shaft Length
|
Spirit 1.0 Evo
Short, Long
|
Spirit 1.0 Evo Remote
Short, Long
|
|
Control
|
Spirit 1.0 Evo
Evo Tiller
|
Spirit 1.0 Evo Remote
Evo Top Mount Control / Evo Side Mount Control / Evo Dual Remote Control
|
|
Hydrogeneration
|
Spirit 1.0 Evo
Yes
|
Spirit 1.0 Evo Remote
Yes
|
|
Motor
|
Spirit 1.0 Evo
Brushless DC motor
|
Spirit 1.0 Evo Remote
Brushless DC motor
|
|
Direct Drive
|
Spirit 1.0 Evo
Yes
|
Spirit 1.0 Evo Remote
Yes
|
|
Maintenance-Free
|
Spirit 1.0 Evo
Yes
|
Spirit 1.0 Evo Remote
Yes
|
What's in the Box
Main Part
Battery Charger
Spirit Battery Plus
(Optional)
Steering Lock
Pin x 2
Tiller Shaft
Lanyard
Invitation Card
Quality Certificate
Spirit Battery Plus
(Optional)
User Manual
Evo Tiller
Kill Switch x 2
Invitation Card
Warranty Card
User Manual
Top Mount Control
Kill Switch x 2
Fixing Guuide
Warranty Card
User Manual
Throttle
Display Panel
Communication
Cable 0.5m
Kill Switch x 2
Screws and Nuts
Warranty Card
Fixing Guide
User Manual
Quick Start
Accessories
FAQ
Yes, but an external battery power cable is required. We recommend the ePropulsion 48V E-Series battery to extend the range.
For more info, please check ePropulsion Blog: How to Find Your Shaft Length
Yes, it is designed for extensive use in the saltwater. ePropulsion uses high-quality aluminum alloy as the base material, and applies an anodizing coating and powder coating on top of it.
For more info, please check ePropulsion Blog: How do we make an outboard corrosion-resistant
Yes, the Spirit 1.0 Plus will switch off after 30 mins without operation.
